Upgrade your pallet racking with robust closed timber decking, designed to provide a continuous, secure surface across the beams.
These decks help support a wide range of pallet types and non-palletised loads, improving safety, load distribution and ease of handling in busy warehouse environments.
Product Features
- Closed timber surface for improved load support and product stability
- Compatible with standard pallet racking beams at 1350 mm or 2700 mm widths
- Available in 900 mm or 1100 mm depths to suit common racking layouts
- High load capacities up to 3000 kg (uniformly distributed)
- Choice of 25 mm or 32 mm thick boards to match application demands
- Ideal for both palletised and loose, irregular or smaller items
- Helps reduce the risk of goods falling through beam gaps
Key Specifications
| Width (mm) | Thickness (mm) | Depth (mm) | Load Capacity (kg) | Configuration |
|---|---|---|---|---|
| 1350 | 25 | 900 | 1000 | Closed timber deck for pallet racking |
| 1350 | 25 | 1100 | 1000 | Closed timber deck for pallet racking |
| 2700 | 25 | 900 | 2000 | Closed timber deck for pallet racking |
| 2700 | 25 | 1100 | 2000 | Closed timber deck for pallet racking |
| 2700 | 32 | 1100 | 3000 | Closed timber deck for pallet racking |
| 2700 | 32 | 900 | 3000 | Closed timber deck for pallet racking |
Applications
- Warehouses storing mixed pallet types and loose cartons
- Distribution centres handling irregular or unstable loads
- Manufacturing facilities requiring continuous shelf support
- Storage of small items that could otherwise fall between beams
- Areas where enhanced safety and load stability are a priority
Frequently Asked Questions
How do I choose the correct depth and width of timber decking for my racking?
Match the deck width to the clear span between your racking uprights (for example 1350 mm or 2700 mm) and the deck depth to the overall racking depth (900 mm or 1100 mm). Always ensure the deck sits fully on the beams and is compatible with your existing layout.
What does the stated load capacity for each deck refer to?
The load capacity shown for each option is the maximum uniformly distributed load that the deck is designed to support when correctly installed on suitable racking beams. Do not exceed these figures and always spread loads evenly across the deck surface.
Can these closed timber decks be used for non-palletised goods?
Yes. The continuous closed surface is particularly useful for boxes, cartons, small components and other loose items that might otherwise fall through or sit unevenly across open beams.
