Protect walkways, machinery and racking with this indoor medium duty impact protection rail system. Combine posts and rails to create clear, robust barriers tailored to your space.
The modular design allows you to configure straight runs, corners and terminations using dedicated end, middle and corner posts with matching safety rails. Ideal for busy industrial and commercial environments where controlled segregation is essential.
Product Features
- Medium duty indoor rail system designed to protect personnel and equipment from low to moderate impacts
- Modular components including end, middle and corner posts for flexible layouts
- Rails available in three standard lengths to suit different run sizes
- Compact 70 mm diameter posts provide strong protection without taking excessive floor space
- 40 mm diameter rails at 60 mm height for clearly visible, continuous barrier lines
- Suitable for defining pedestrian routes, restricted zones and equipment areas
Key Specifications
| Component type | Overall height | Overall length | Tube diameter | Typical use |
|---|---|---|---|---|
| Indoor end post | 1000 mm | 70 mm | 70 mm | Termination of rail runs |
| Indoor middle post | 1000 mm | 70 mm | 70 mm | Intermediate support in straight runs |
| Indoor corner post | 1000 mm | 70 mm | 70 mm | Direction changes and corner protection |
| 1 m indoor rail | 60 mm | 1000 mm | 40 mm | Short barrier sections |
| 1.2 m indoor rail | 60 mm | 1200 mm | 40 mm | Medium-length runs |
| 1.5 m indoor rail | 60 mm | 1500 mm | 40 mm | Longer continuous barriers |
Applications
- Defining pedestrian walkways in warehouses and factories
- Protecting racking, machinery and building columns from impact
- Creating safety zones around equipment and loading areas
- Separating vehicle routes from foot traffic indoors
- Marking restricted or controlled access areas
Frequently Asked Questions
Can I mix different rail lengths within the same barrier run?
Yes, the system is modular, so you can combine 1 m, 1.2 m and 1.5 m rails in any sequence, using the appropriate posts to achieve the overall length and layout you need.
Are the posts suitable for forming both straight and corner sections?
Yes, there are dedicated middle posts for straight runs and corner posts for direction changes, allowing you to build continuous barriers around obstacles and along walls.
Is this system intended for indoor use only?
This rail system is specified for indoor applications and is ideal for internal warehouse, factory and commercial environments where medium duty impact protection is required.
