Efficiently raise and lower loads in workshops, warehouses and dispatch areas with this mobile double scissor lift table. Designed for secure handling, it combines a stable double-scissor mechanism with a compact footprint for easy manoeuvrability.
With models covering capacities from 150kg to 500kg, this hydraulic lift table offers smooth lifting through a wide height range, helping to reduce manual handling strain and improve productivity at the point of work.
Product Features
- Mobile hydraulic lift table for safe, controlled raising and lowering of loads
- Double scissor design provides increased lift height within a compact platform size
- Load capacities from 150kg up to 500kg to suit light to heavier-duty applications
- Smooth-rolling castors with rubber or polyurethane tyres for easy positioning
- Clearly defined platform lift range with specified minimum and maximum heights
- Manual pump operation with a known number of compressions to reach maximum height
- Durable construction for everyday use in industrial and commercial environments
Key Specifications
| Load capacity options | 150kg or 500kg |
|---|---|
| Platform width options | 500mm or 520mm |
| Platform length options | 815mm or 1010mm |
| Minimum platform height | 380mm or 435mm |
| Maximum platform height | 1350mm or 1605mm |
| Number of pump compressions to reach max height | 29 (150kg model) or 90 (500kg model) |
| Wheel diameter | 100mm (150kg model) or 150mm (500kg model) |
| Wheel tyre material | Rubber (150kg model) or polyurethane (500kg model) |
| Configuration | Mobile double scissor lift table |
Applications
- Loading and unloading goods at workbenches, packing stations and assembly lines
- Handling boxes, components and equipment in warehouses and stockrooms
- Supporting maintenance tasks where adjustable working height is required
- Positioning materials in production and manufacturing environments
- Reducing manual lifting and lowering in dispatch and goods-in areas
Frequently Asked Questions
What load capacities are available for this double scissor lift table?
This mobile lift table is available in two versions with rated load capacities of 150kg or 500kg, allowing you to choose a model that safely supports the weights you handle most frequently.
What is the lifting height range of the platform?
Depending on the model, the platform can be lowered to either 380mm or 435mm and raised to a maximum height of 1350mm or 1605mm. This provides a broad working range for lifting, positioning and transferring loads.
How is the lift table moved and operated?
The table is mounted on castor wheels for easy movement and positioning. Lifting is achieved via a manual pump, with a specified number of compressions required to reach the maximum platform height for each capacity option.
